| Nominal sensing distance | 900mm |
| Thermal drift of Sr | ±2% |
| Repeat Accuracy | 0,50% |
| Sensitivity adjustment | Teach-in button |
| thermal compensation | |
| Minimum sensing distance (blind zone) | 100mm |
| Function Principle | Diffuse reflection |
| Output type | IO-Link/PNP + 4…20mA |
| Output Function | NO/NC + positive/negative slope |
| Switching frequency | 3Hz |
| Operating Voltage | 10 - 30Vdc |
| No-Load supply current | ≤50mA |
| Load current | 100mA |
| Leakage current | 10μA @ 30Vcc |
| Max ripple content | 5% |
| LED indicators | green: echo - yellow: output |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Impulsive Overvoltage Protection | Yes |
| Dimensions | M18 x 1 / L = 91,6mm |
| Housing material | stainless steel AISI 316L |
| Weight | 100g |
| Connections | M12 Plug |
| Active Head Material | 10° ± 2° |
| Tightening torque | 1Nm |
| Operating temperature | - 20°C…+ 70°C |
| Storage temperature | - 35°C…+ 80° C without freeze |
| Diameter/Dimension | M18 |
| Approvals | CE cULus |
| EMC compatibility | IEC 60947-5-2 |
| Shocks and vibrations | IEC EN60947-5-2 / 7.4 |
| Degree of protection | IP67 |
| Supplied Accessories | 2 x M18 x 1 nuts, 2 Ø 18 washers |
| Dimensions | M18 x 1 / L = 91,6mm |
| Operating Temperature | - 20°C…+ 70°C |
| Mechanical Protection | IP67 |
