| Nominal sensing distance | 2m |
| Sensitivity adjustment | Trimmer |
| Function Principle | Diffuse beam |
| Description | Compact square case |
| Functions | Diffuse beam |
| Output type | Relay SPDT L/D selectable by trimmer |
| Output Function | L/D selectable by trimmer |
| Switching frequency | 16Hz |
| Response time | 30ms |
| Operating Voltage | 24...240 VAC |
| No-Load supply current | ≤ 40mA |
| Load current | ≤3A |
| LED indicators | Red OUTPUT |
| Emission | LED Infrared |
| Interference to external light | according to EN 60947-5-2 : 2020 |
| Insulation resistance | >20 MΩ 500 Vdc, between electronics and housing |
| Contact resistance | 500 Vac 1 min., between electronics and housing |
| Dimensions | 18x50x50 |
| Housing Material | ABS |
| Connections | 2m cable |
| Active Head Material | PMMA |
| Storage temperature | - 25°C…+70°C |
| Material | |
| Diameter/Dimension | Cubic |
| Approvals | CE cULus |
| EMC compatibility | EN 60947-5-2 |
| Shocks and vibrations | 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6) |
| Dimensions | 18x50x50 |
| Operating Temperature | - 25°C…+ 55°C (Without freeze) |
| Mechanical Protection | IP65 |
