Home > Products > Sensors > Photoelectric sensors > Cubic sensors > RX > RXE/00-3A

RX

RXE/00-3A

Photo.Maxi,IR emiss.,M12 plug,Emitter
Photoelectric sensor maxi Emitt. 20...253Vac/ 20...60Vdc NO/NC Relay without fixing slide conn. M12

Maxi with static output DC or with relay output AC/DC

Overview

  • Models: diffuse reflection, retro-reflective, polarized, through-beam and background suppression
  • Series with high performances and wide possibilities of installation
  • High sensing distance and very small dimensions
  • Relay output or multifunctional DECOUT®
  • Timer function delay on, delay off, one shot; trimmer for sensitivity adjustment
  • Switch reducing the emission for fine detection in through-beam types
  • LED alignment indicator with 360° visibility, 2 LED indicators (stable signal, output)
  • M12 standard plug cable exit; axial and right angle brackets

Technical Features

Detection properties
Nominal sensing distance 16-32m selectable with switch
Thermal drift of Sr 10% Sr
Repeat Accuracy 5%
Application
Function Principle Emitter
Optic position Axial
Outputs
Output type Relay SPST
Output Function
Switching frequency
Electrical data
Operating Voltage 20...60VDC /20...253VAC/50-60Hz
No-Load supply current ≤ 15mARMS
Load current 3A-250Vac/3A-30Vdc (750VA/90W)
Max ripple content ≤10%
LED indicators Green (check), Red (x 2 distance)
Time delay before availability ≤200ms
Reverse Polarity Protection Yes
Emission LED Infrared (880nm)
Interference to external light
Impulsive Overvoltage Protection Yes
Mechanical data
Dimensions 26x86,6x50
Housing material PC
Weight 75g
Connections M12 plug
Active Head Material PMMA
Operating temperature - 25°C…+ 70°C ( without freeze)
Diameter/Dimension Cubic
Test/Approvals
Approvals CE
EMC compatibility EN 60947-5-2
Shocks and vibrations Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
Degree of protection IP65
Accessories
Supplied Accessories ST80 mounting bracket and screws
Generical Data
Dimensions 26x86,6x50
Operating Temperature - 25°C…+ 70°C (Without freeze)
Mechanical Protection IP65

Connections

Eletrical diagram
Connector

Others

Dimensions
Response curves

Downloads for RXE/00-3A
