| Nominal sensing distance | 8m |
| Sensitivity adjustment | No |
| Hysteresis | +/- 1% |
| Function Principle | Receiver |
| Notes | (3m for car washes) |
| Output type | PNP Lon |
| Output Function | Lon |
| Response time | <10 ms |
| Operating Voltage | 19,2 … 28,8VDC |
| Load current | ≤30mA |
| LED indicators | Green (RUN) Yellow (status output) Red (problem with otput) |
| Time delay before availability | ≤200ms |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Impulsive Overvoltage Protection | Yes |
| Digital Resolution | 12 bit |
| Housing material | PBT + PC |
| Weight | 571 g la coppia |
| Connections | 5m PVC cable |
| Active Head Material | PC |
| Tightening torque | 1Nm |
| Operating temperature | -20..60°C (without freeze) |
| Storage temperature | -30..90°C (without freeze) |
| Approvals | CE |
| EMC compatibility | EN 60947-5-2 |
| Degree of protection | IP67 (front-head IP69K) |
| Operating Temperature | - 20°C…+ 70°C (Without freeze) |
| Mechanical Protection | IP67 (front-head IP69K) |
