| Distance with SSF | 90 mm |
| Distance with FS1 | 90 mm |
| Distance with FX3 | 600 mm |
| Distance with FX4 | 900 mm |
| Distance with F1R | 410 mm |
| Function Principle | Emitter + Receiver |
| Description | Glass fibres up to 250°C |
| Optic position | Axial |
| Operating temperature | -40°C....+250°C (posa fissa) |
| Fibre lengh (m) | 2 |
| Ø optical fibre core | 1 |
| Head shape | M4 |
| Optical fibre material | glass, ETM, inox |
| Head material | nickel-plated brass |
| Degree of protection | IP67 |
| Accessories to be ordered separately | vedi serie AF |
| Operating Temperature | -40°C....+250°C (posa fissa) |
| Mechanical Protection | IP67 |
