| Fixing | spring terminals |
| Rated current | a 40℃ 4 A |
| Led | no |
| Wires | 3 |
| Insulation resistance | ≥ 100 mΩ |
| Contact resistance | ≤ 5 mΩ |
| Rated voltage | 60 V (3 plugs) 30 V (4 plugs) |
| Tightening torque | 0,6 Nm (pressure nut) 0,2 Nm (M8 nut) |
| Operating temperature | -25 °C ... 80 °C |
| Head type | Axial |
| Plug | M8 |
| Outer diameter | 2,5 mm...5 mm ±0,2 mm |
| Stripping lenght of the sheath | 40 mm |
| AWG conductors section | AWG 24 ... 20 |
| Conductors section | 0,25 mm²...0,5 mm² |
| Model | Male |
| Degree of protection | IP65 / IP67 |
| Operating Temperature | -25 °C ... 80 °C |
| Mechanical Protection | IP65 / IP67 |
