| Fixing | screw terminals |
| Rated current | 4 A |
| Led | no |
| Wires | 5 |
| Insulation resistance | ≥ 100 mΩ |
| Contact resistance | ≤ 5 mΩ |
| Rated voltage | 250 V |
| Connections | Field attachable |
| Operating temperature | -25 °C ... 90 °C |
| Head type | 90° |
| Plug | M12 |
| Outer diameter | 3 mm ... 6,5 mm |
| Stripping lenght of the sheath | 20 mm |
| Conductors section | 5 |
| Model | Female |
| Degree of protection | IP67 |
| Operating Temperature | -25 °C ... 90 °C |
| Mechanical Protection | IP67 |
