| Fixing | screw terminals |
| Rated current | a 40°C 4 A |
| Led | no |
| Wires | 4 |
| Insulation resistance | ≥ 100 MΩ |
| Contact resistance | ≤ 5 mΩ |
| Rated voltage | 60 V (3 plugs) 30 V (4 plugs) |
| Connections | Field attachable |
| Tightening torque | 0,2 Nm (M8 nut) |
| Operating temperature | -40 °C ... 85 °C |
| Head type | Axial |
| Plug | M8 |
| Outer diameter | 3,5 mm ... 5 mm |
| Stripping lenght of the sheath | 12 mm |
| Wire isolation | ≥ 100 MΩ |
| Conductors section | 0,14 mm²...0,5 mm² |
| Model | Female |
| Degree of protection | IP67 |
| Operating Temperature | -40 °C ... 85 °C |
| Mechanical Protection | IP67 |
