| Nominal current | 2 A |
| Led | no |
| Wires | 8 |
| Rated impulse voltage | 1,5 kV |
| Nominal voltage | Max. 30 V ac/dc |
| Connections | With open ended wires |
| Tightening torque | 0,6 Nm |
| Operating temperature | -25°C...+80°C (flexible installation)-25°C...+80°C (fixed installation) |
| Fibre lengh (m) | 10 |
| Head type | Axial |
| Plug | M12 |
| Outer diameter | Ø 6,4 mm ± 0,2 mm |
| Jacket material | TPU |
| Wire isolation | PP |
| Conductors section | 0,34 mm2 (42 x 0,10 mm2) |
| Model |
| Degree of protection | IP67 |
| Operating Temperature | -25°C...+80°C (flexible installation)-25°C...+80°C (fixed installation) |
| Mechanical Protection | IP67 |
