| Nominal current | Max. 4 A |
| Led | |
| Wires | 4 |
| Rated impulse voltage | 2,5 kV |
| Nominal voltage | Max. 250 V ac/dc |
| Connections | |
| Tightening torque | 0,6 Nm |
| Operating temperature | Plug : -25°C … +85°C Fixed installation : -30°C … +80°C Flexible installation: -5°C … +80°C |
| Fibre lengh (m) | 5 |
| Head type | 90° |
| Plug | M12 |
| Outer diameter | Ø 5 mm ± 5% |
| Jacket material | PVC (CFC, cadmium, silicon, lead free) Flame retardant according to UL1581VW1/CSA FT1, self-extinguishing |
| Wire isolation | PVC (CFC, cadmium, silicon, lead free) |
| Bending radius | Wire for fixed installation: 5 x d Wire for flexible installation: 10 x d |
| Conductors section | 0,34 mm2 (19 x 0,15 mm2) |
| Model |
| Degree of protection | IP67 |
| Operating Temperature | Plug : -25°C … +85°C Fixed installation : -30°C … +80°C Flexible installation: -5°C … +80°C |
| Mechanical Protection | IP67 |
