| Nominal sensing distance | 8mm |
| Thermal drift of Sr | < 20% |
| Repeat Accuracy | 5% |
| Sensitivity adjustment | Yes |
| Hysteresis | ≤ 20% |
| Output type | NPN, PNP, Push-pull, IO-Link |
| Output Function | NO+NC/IO-Link |
| Switching frequency | 50Hz |
| Operating Voltage | 10...40Vdc |
| No-Load supply current | ≤ 20mA |
| Load current | ≤ 200mA |
| Leakage current | ≤ 100µA |
| Output voltage drop | ≤ 1.0 VDC @ 200 mA DC |
| Max ripple content | ≤10% |
| LED indicators | Yellow LED (object detected), green LED power supply/stability |
| Time delay before availability | ≤300ms |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Impulsive Overvoltage Protection | Yes |
| Mounting | Shielded |
| Weight | 62g |
| Housing Material | PTFE |
| Connections | M12 plug |
| Active Head Material | PTFE |
| Tightening torque | ≤ 1 Nm |
| Storage temperature | -40°C…+85°C |
| Diameter/Dimension | M18 |
| Approvals | CE cULus IO-Link ECOLAB |
| EMC compatibility | EN60947-1; IEC 61000-4-2; IEC 61000-4-3; IEC 61000-4-4 |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-27 |
| Supplied Accessories | screw driver, 2 x M18 nuts |
| Dimensions | M18 / L = 85mm |
| Operating Temperature | -30°C…+85°C (without freeze) |
| Mechanical Protection | IP68, IP69K |
