| Nominal sensing distance | depending on the receiver |
| Thermal drift of Sr | ≤10% |
| Beams space | 6mm |
| controlled height | 70mm |
| minimum detectable object | Depending on the receiver |
| number of rays | 12 |
| Sensitivity adjustment | Yes |
| Function Principle | Emitter |
| Output type | Emitter |
| Output Function | Emitter |
| Operating Voltage | 12…24 VDC |
| No-Load supply current | 100mA |
| Max ripple content | ≤ 10% |
| LED indicators | Green (powerON) |
| Time delay before availability | 500ms |
| Short-circuit protection | Yes (auto reset) |
| Reverse Polarity Protection | Yes |
| Emission | Infrared (880nm) |
| Interference to external light | 1.500 lux max. (incandescent lamp), 4.500 lux max. (sunlight) |
| Impulsive Overvoltage Protection | Yes |
| Dimensions | 44mm x 120mm x 20mm |
| Housing material | PBT |
| Weight | 800 … 820g |
| Connections | PVC 5m cable |
| Active Head Material | PC |
| Tightening torque | 25Nm |
| Operating temperature | -25°C…+50°C (without freeze) |
| Storage temperature | -40°C…+80°C |
| Approvals | CE cULus |
| EMC compatibility | IEC 60947-5-2 |
| Shocks and vibrations | IEC EN 60947-5-2 |
| Degree of protection | IP67 |
| Supplied Accessories | 2 nuts M18x1 - 1 adjustment key - 1 90°angled brackets |
| Dimensions | 45x145x20 |
| Operating Temperature | -25°C…+50°C (without freeze) |
| Mechanical Protection | IP67 |
