| Nominal sensing distance | 0 … 2m |
| Thermal drift of Sr | ≤10% |
| Beams space | 6mm |
| controlled height | 70mm |
| minimum detectable object | Ø 6mm |
| number of rays | 12 |
| Function Principle | Receiver |
| Output type | PNP |
| Output Function | NO/NC |
| Response time | 10ms |
| Operating Voltage | 12…24 VDC |
| No-Load supply current | 50mA |
| Load current | ≤100mA |
| Leakage current | 10µA |
| Output voltage drop | ≤1.2V Iload =100mA |
| Max ripple content | ≤ 10% |
| LED indicators | Green (powerON), red (alignment), yellow (output state) |
| Time delay before availability | 500ms |
| Short-circuit protection | Yes (auto reset) |
| Reverse Polarity Protection | Yes |
| Interference to external light | 1.500 lux max. (incandescent lamp), 4.500 lux max. (sunlight) |
| Impulsive Overvoltage Protection | Yes |
| Dimensions | 44mm x 120mm x 20mm |
| Weight | 800 … 820g |
| Housing Material | PBT |
| Connections | PVC 2m cable |
| Active Head Material | PC |
| Tightening torque | 25Nm |
| Operating temperature | -25°C…+50°C (without freeze) |
| Storage temperature | -40°C…+80°C |
| Approvals | CE cULus |
| EMC compatibility | IEC 60947-5-2 |
| Shocks and vibrations | IEC EN 60947-5-2 |
| Degree of protection | IP67 |
| Supplied Accessories | 2 nuts M18x1 - 1 adjustment key - 1 90°angled brackets |
| Dimensions | 45x145x20 |
| Operating Temperature | -25°C…+50°C (without freeze) |
| Mechanical Protection | IP67 |
