| Nominal sensing distance | 0,3 … 6m |
| Thermal drift of Sr | ≤10% |
| Beams space | 10mm |
| controlled height | 90mm |
| minimum detectable object | Ø 5mm |
| number of rays | 10 |
| Sensitivity adjustment | Trimmer |
| Function Principle | Emitter |
| Output type | Emitter |
| Output Function | Emitter |
| Operating Voltage | 10…26VDC |
| No-Load supply current | 25mA |
| Max ripple content | ≤ 10% |
| LED indicators | Green (powerON) |
| Time delay before availability | ≤ 85ms |
| Reverse Polarity Protection | Yes |
| Emission | Infrared |
| Interference to external light | 1000lux (incandescent lamp), 1500lux (sunlight) |
| Housing material | PBT |
| Weight | 140g |
| Connections | cable PVC 200mm + M12 Plug |
| Active Head Material | PC |
| Tightening torque | 25Nm |
| Approvals | CE |
| EMC compatibility | EN 60947-5-2 |
| Supplied Accessories | 2 nuts M18x1 - 1 adjustment key - 1 90°angled brackets |
| Dimensions | 45x145x20 |
| Operating Temperature | 0°C…+ 50° C (without freeze) |
| Mechanical Protection | IP67 |
