| Nominal sensing distance | 200mm |
| Repeat Accuracy | ≤ 5% |
| Sensitivity adjustment | Trimmer |
| Function Principle | Diffuse reflection (short distance, ≤200mm) |
| Optic position | Axial |
| Output type | TRIAC NO/NC |
| Output Function | NO/NC |
| Switching frequency | 25Hz |
| Response time | 20ms |
| Operating Voltage | 20...253VAC/50-60Hz |
| No-Load supply current | 1,5W |
| Load current | 5…300mARMS |
| Leakage current | 1,5m ARMS max ( supply V=253Vac) |
| Output voltage drop | ≤2,5V@Iload=300mARMS |
| LED indicators | Red (output status) |
| Time delay before availability | 200ms |
| Short-circuit protection | Yes |
| Reverse Polarity Protection | Yes |
| Emission | LED Infrared (880nm) |
| Interference to external light | 3000lux Incandescent Lamp, 10000lux |
| Dimensions | 16x37x64 |
| Material | |
| Housing material | ABS |
| Weight | 185g |
| Connections | 2m PVC cable 90° |
| Active Head Material | PMMA |
| Operating temperature | - 25°C…+ 70°C ( without freeze) |
| Diameter/Dimension | Cubic |
| Approvals | CE |
| EMC compatibility | EN 60947-5-2 |
| Shocks and vibrations | Vibration IEC 60068-2-6 / Shock IEC 60068-2-44 |
| Degree of protection | IP65 |
| Supplied Accessories | ST01 mounting brakets and screws |
| Dimensions | 16x37x64 |
| Operating Temperature | - 25°C…+ 70°C (Without freeze) |
| Mechanical Protection | IP65 |
