Safety laser scanner based on Time of Flight measurement with command integration in Profinet/Profisafe fieldbus.
| Detection capability | 0 |
| Angular resolution | 0,1° |
| Safety range ( min) | 0,05 m |
| Safety range (max) [ detection capability] | 2,5m[30mm]; 3m[40mm]; 4m[50mm]; 5,5m[70,150mm] |
| warning range (max) | 40 m |
| Detectable target remission | 1,8% .. ""1000%"" |
| N°of simultaneous safety zone (max) | 8 |
| N°of simultaneous warning zone (max) | 7 |
| N°of zone set (max) | 70 |
| N°of reference point set (max) | 70 |
| Response time max | 94 ms - 1750 ms (Fast Mode), 105 ms - 2065 ms (Standard Mode) |
| Tolerance Zone | 100 mm |
| Supplement for retroreflectors on scan plane in front of a safety zone | 200 mm |
| Type | 3 (EN 61496-1) |
| SIL | SIL 2 (IEC 61508) SIL 2 (EN 62061) |
| Cat. | (EN ISO 13849-1) |
| PFHd | 2.24 x 10-8 |
| MTTFd | 61 years |
| TM (Mission Time) | 20 years (EN ISO 13849-1) |
| Power Supply | 16.8 Vdc ... 28.8 Vdc |
| Power consumption | 8.5 W @24 V, no digital I/O connected |
| Protection class | III (EN/IEC 61140) |
| Dimensions | 102x113x152 mm |
| Material | Metal - Aluminium / PMMA |
| Housing material | Painted alumininium / PC |
| Optic window material | PMMA |
| N° of configurable input (max) | 5 |
| N° of configurable output (max) | 4 |
| Network Interfaces | 10/100 Mbit/s Ethernet (3X) |
| PROFINET specification | V2.43 |
| PROFIsafe specification | V2.6.1 & 2.4 (w/o iPar) / Conformance class B |
| GSDML specification | V2.43 |
| Power and I/0 | M12 male type A connector - 8 poles |
| Ethernet to GUI / Data transmission | M12 male type D connector - 4 poles |
| Profinet / Profisafe | M12 male type D connector - 4 poles (2X) |
| Configuration and monitoring interfaces | DL Sentinel 4.0.x |
| LED indicators | TX: Green (Power ON), Yellow (Emission range) Red (Test, failure, Firmware ongoing update), Blue (Emission range, Firmware update completed) RX: Green (Power ON), Yellow (Status output, Connection and teach-in active) Red (Hardware Errors, Invalid con |
| Humidity | 95% max non-condensing |
| Enclosure | IP65 |
| Operating Temperature | -10 ... 50 °C |
| Storage temperature | -20 ... 70 °C |
| Vibration Resistance | According to IEC 61496-1 (4.3.3.1;4.3.3.2;5.4.4.1) Class 3M7 (Stationary Use) Class 5M1 (Ground vehicle Installation) |
| Shock Resistance | According to IEC 61496-1 (4.3.3.1;4.3.3.3;5.4.4.2) IEC 61496-3 (5.4.4); IEC 60068-2-75 Class 3M7 (Stationary Use) Class 5M1 (Ground vehicle Installation) |
| Laser Wavelength | 905 nm |
| Laser Pulse duration | 3 ns |
| Laser class/Laserklass | CLASS 1 (EN 60825-1:2014) |
| Generic Alarm | Available |
| Clean Window Alarm | Available |
| Muting enable | Not Available |
| Muting | Available |
| Override | Available |
| Dust Filtering | Available |
| EDM (External Device Monitoring) | Not Available |
| Partial Muting | Available |
| Pre-alarm (warning) | Available |
| Advanced Data transfer protocol | Available |
| Reset( restart cycle) | Available |
| Manual/automatic restart | Available |
| Shut-off (mute) | Available |
| Dynamic Reference Points | Available |
| Encoder input | Not Available |
