| Nominal sensing distance | 100mm |
| Sensitivity adjustment | n/a |
| Function Principle | Diffuse beam |
| Description | Tubular M18 - axial optic |
| Functions | Diffuse beam |
| Output type | PNP L/D selectable |
| Output Function | L/D selectable |
| Response time | 1 |
| Operating Voltage | 10…30VDC |
| No-Load supply current | ≤ 35mA |
| Load current | ≤100mA |
| Output voltage drop | ≤2V@Iload=100mA |
| Short-circuit protection | YES |
| Reverse Polarity Protection | Yes |
| Emission | LED Red |
| Interference to external light | according to EN 60947-5-2 : 2020 |
| Impulsive Overvoltage Protection | Yes |
| Insulation resistance | >20 MΩ 500 Vdc, between electronics and housing |
| Contact resistance | 500 Vac 1 min., between electronics and housing |
| Dimensions | Ø18x57 |
| Housing Material | Plastic PBT / PMMA |
| Connections | M12 plug |
| Active Head Material | PMMA |
| Storage temperature | - 25°C…+70°C |
| Material | |
| Diameter/Dimension | M18 |
| Approvals | CE cULus |
| Shocks and vibrations | 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6) |
| Supplied Accessories | nuts M18 x 1 |
| Dimensions | M18 x 1 /L=57 |
| Operating Temperature | - 25°C…+ 55°C (Without freeze) |
| Mechanical Protection | IP67 |
