Technical features

Detection properties

Nominal sensing distance 20m
Thermal drift of Sr 10% Sr
Repeat Accuracy 5%
Sensitivity adjustment No


Function Principle Receiver
Emitter/Receiver Receiver
Optic position Axial


Output type PNP NO+NC
Output Function NO+NC
Switching frequency 250Hz
Response time 2ms

Electrical data

Operating Voltage 10…30VDC
No-Load supply current ≤ 25mA
Load current ≤100mA
Leakage current ≤10μA
Output voltage drop ≤2V@Iload=100mA
Max ripple content ≤10%
LED indicators Yellow Output state ,
Time delay before availability ≤200ms
Short-circuit protection Yes
Reverse Polarity Protection Yes
Interference to external light 5.000lux (incandescent lamp), 10.000lux (sunlight)

Mechanical data

Dimensions M18x1/L=83mm
Weight 60g
Housing Material Stainless steel AISI 316L / PA12 plug
Connections M12 plug
Active Head Material PA12
Tightening torque 50Nm
Operating temperature -25°C…+80°C (without freeze)
Diameter/Dimension M18


Approvals CE cULus ECOLAB Diversey
EMC compatibility EN 60947-5-2
Shocks and vibrations Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protection IP68, IP69K


Supplied Accessories Nuts M18 x 1

Generical Data

Dimensions M18x1/L=83mm
Operating Temperature - 25°C…+ 80°C (Without freeze)
Mechanical Protection IP68, IP69K
